Standalone Voice/IP GatewayModel MVP800Proprietary ModeQuick Start Guide

MultiVOIP Quick Start Guide10E&M Jumper Block Positioning ProcedureA jumper block exists for each voice/fax channel. The jumperblock is to the ri

11CablingPhillips quarter-turn screws and replace the four Phillipsscrews on the back and the four Phillips screws on thebottom.8. If you are using a

MultiVOIP Quick Start Guide12Configuring Your Host MultiVOIPThe following software loading procedure does not provideevery screen or option in the loa

13Software InstallationIf the Multi-Tech Installation CD window does not displayautomatically, click My Computer, then right click the CDROM drive ico

MultiVOIP Quick Start Guide14Click Next to continue.5. Follow the on-screen instructions to install your MultiVOIPsoftware.You may choose the Destinat

15Software InstallationClick OK to continue.7. The Setup Complete dialog displays.Click Finish to continue.8. The following message displays:Click Yes

MultiVOIP Quick Start Guide1610. In the Ethernet group, enter the IP Address, SubnetMask, and Gateway Address, unique to your IP LAN.The IP address is

17Software Installationpanel of the MultiVOIP.If you are connecting a station device such as an analogtelephone, a fax machine, or a Key Telephone Sys

MultiVOIP Quick Start Guide18dialing a phone number. The default setting is 5. In theInter Digit Time box, enter the maximum amount of timein millis

19Software Installationchannel’s configuration to any other channel by clickingCopy. Everything on the Interface tab will be copied tothe other chann

Quick Start GuidePN 82088350 Revision AMultiVOIP 800 (Model MVP800)This publication may not be reproduced, in whole or in part, without priorexpressed

MultiVOIP Quick Start Guide20Note: Only change the DTMF gain under the direction ofMulti-Tech Technical Support.16. The Fax group enables you to send

21Software Installation19. The Call Authentication option enables passwordprotection for outbound and inbound calls on the selectedvoice/fax channel.

MultiVOIP Quick Start Guide22following steps.The MultiVOIP configured as a “Host” will contain the hostdatabase. The host database has the phone numbe

23Software Installation25. The Description is optional, but can be useful inassociating the channel to the extension. If you want, entera description

MultiVOIP Quick Start Guide2428. Click OK and you are returned to the Phone DirectoryDatabase dialog box, which now includes phone number101 with its

25Software Installation31. Enter a description for the remote MultiVOIP phonenumber for Channel 1 in the Description box.Note: If the remote MultiVOIP

MultiVOIP Quick Start Guide26Note: If only Channel 1 is active, you must enter twophone numbers. The first number is the local MultiVOIPphone number f

27Software Installation38. Windows 3.1 users - you are returned to your ProgramManager where the MultiVOIP Program Group andProgram Item (Windows icon

MultiVOIP Quick Start Guide281. Disconnect the pc from the command port of the HostMultiVOIP and connect it to the command port on theClient MultiVOIP

29Software Installation4. In the Port Address group, enter the IP Address and IPMask. In the Gateway Address group, enter the gatewayIP address for th

iiiContentsIntroduction ... 4Related Documentation ...

MultiVOIP Quick Start Guide30If you are connecting a station device such as an analogtelephone, a fax machine, or a Key Telephone System(KTS) to the V

31Software Installationin milliseconds that the unit will wait before mapping thedialed digits to an entry in the Phone Directory Database.If too much

MultiVOIP Quick Start Guide327. Repeat the above steps to configure the interface type foreach voice/fax channel.The Voice/Fax tab displays the parame

33Software Installation10. The Fax group enables you to send and receive faxes onthe selected voice/fax channel. You can select themaximum baud rate

MultiVOIP Quick Start Guide3413. The Call Authentication option enables passwordprotection for outbound and inbound calls on the selectedvoice/fax cha

35Software Installation16. Click OK after the download is complete. Click Start |Programs| MultiVOIP 800 v. 301E | MultiVOIPConfiguration. At the ma

MultiVOIP Quick Start Guide3618. Click OK and you are returned to the main menu.19. Click Download Setup to write the new configuration tothe client u

37Software InstallationDeploying the VOIP NetworkDeploying the VOIP network involves the VOIP Administratordeveloping the VOIP Dialing Directory and d

MultiVOIP Quick Start Guide38Remote Site Administrator3. Unpack your MultiVOIP.4. Connect one end of the power supply to a live AC outletand connect t

39Software Installationon the back of the MultiVOIP and the other end to thetrunk phone jack. Refer to the MultiVOIP User Guide forE&M pin assignm

MultiVOIP Quick Start Guide4IntroductionWelcome to Multi-Tech's new standalone Voice/IP Gateways,which allow analog voice and fax communication o

MultiVOIP Quick Start Guide40Limited WarrantyMulti-Tech Systems, Inc. (“MTS”) warrants that its products willbe free from defects in material or workm

41Software InstallationContacting Technical SupportCountry By E-mail By telephoneFrance: [email protected] (33) 1-64 61 09 81India: sup

MultiVOIP Quick Start Guide42

82088350

5IntroductionSystem CD with your MVP800. The User Guide provides in-depth information on the features and functionality of Multi-Tech’s MultiVOIP. Th

MultiVOIP Quick Start Guide6configures the unit and builds the Phone Directory Databasethat will reside in the Host unit.Configure your Client MultiVO

7CablingUnpacking Your MultiVOIPRemove all items from the box.www.multitech.comVoice/Fax over IP NetworksFigure 3. UnpackingSafety WarningsCaution:

MultiVOIP Quick Start Guide8 Cabling Your MultiVOIPCabling your MultiVOIP involves connecting the hostMultiVOIP to your LAN and telephone equipment.If

9Cabling3. Connect a network cable to the ETHERNET 10BASETconnector on the back of the MultiVOIP. Connect the otherend of the cable to your network.4.
