26 CommPlete 4000 Communications Server Overview

Chassis Mounting

Screws

BANK 1

SOCKET 7

LOCK

Fig. 4-4. Chassis Mounting Screw

4 Finish pulling the card cage (including fan enclosure) straight up and out of the chassis.

See Figure 4-5. Set it next to the chassis.

Note: Before placing the card cage back into the chassis, verify that the power connectors

from the power supply to the backplane are fully attached. Figure 4-5b shows the wire colors

and correct orientation of the power cables.

ISI (3)

SBC Board

BANK 1

SOCKET 7

LOCK

BANK 1

Ethercard

BANK 1

CKET 7

LOCK

Fan Enclosure

Figure 4-5. Card Cage Removal
