CUSTOMATCOMMANDS



207 ATCommandsforHSPA‐H5Modems



 TheinstanceusedfortheEvMoniserviceisthesameusedfortheSMSATRUNservice.Therefore,whenthe

#ENAEVMONICFGsetsthe<instance>parameter,thechangeisreflectedalsointhe<instance>parameterof

the#SMSATRUNCFGcommand,andviceversa.

 ThesetcommandreturnsERRORifthecomman dAT#ENAEVMONI?returns1as<mod>parameter orthe

commandAT#SMSATRUN?returns1as<mod>parameter

EventMonitoring#EVMONI

Setcommandenablesordisablesthesingleeventmonitoring, configuresther elatedparameterandassociates

theATcommand.

Readcommandreturnsthecurrentsettingsforeacheventintheformat:

#EVMONI:<label>,<mode>,<param0>[,<param1>[,<param2>[,<param3>]]]

Where<param0>,<param1>,<param2>and<param3>aredefinedasbeforefor<param>dependingon

<label>value.

Testcommandreturns

valuessupportedasacompoundvalue.

Syntax

Command Commandtype

AT#EVMONI=<label>,<mode>,[,<paramType>,<param>] Set

AT#EVMONI? Read

AT#EVMONI=? Test

ParametersandValues

<label>

Stringparameter—enclosedbetweendoublequotes—indicatingtheeventunder

monitoring.Itcanassumethefollowingvalues:

VBATT Batteryvoltagemonitoring.Notyetimplemented.

DTR DTRmonitoring.Notyetimplemented.

ROAM Roamingmonitoring.

CONTDEACT Contextdeactivationmonitoring.

RING Callringingmonitoring.

STARTUP Modulestart‐upmonitoring.

REGISTERED Networkregistrationmonitoring.

GPIO1 Monitoring

onaselectedGPIOintheGPIOrange.

GPIO2 MonitoringonaselectedGPIOintheGPIOrange.

GPIO3 MonitoringonaselectedGPIOintheGPIOrange.

GPIO4 MonitoringonaselectedGPIOintheGPIOrange.

GPIO5 MonitoringonaselectedGPIOintheGPIOrange.

ADCH1 ADC

highvoltagemonitoring.

ADCL1 ADClowvoltagemonitoring.

DTMF1 MonitoringonuserdefinedDTMFstring.

DTMF2 MonitoringonuserdefinedDTMFstring.

DTMF3 MonitoringonuserdefinedDTMFstring.

DTMF4 MonitoringonuserdefinedDTMFstring.
