Appendix E – Regulatory Compliance

Multi-Tech Systems, Inc. RF550VPN User Guide 67

EMC, Safety, and R&TTE Directive Compliance

The CE mark is affixed to this Multi-Tech product to confirm compliance with the following European Community

Directives:

Council Directive 89 / 336 / EEC of 3 May 1989 on the approximation of the laws of Member States relating to

electromagnetic compatibility.

and

Council Directive 73 /23 / EEC of 19 February 1973 on the harmonization of the laws of Member States relating

to electrical equipment designed for use within certain voltage limits:

and

Council Directive 1999 / 5 / EC of March 1999 on radio equipment and

telecommunications terminal equipment

and the mutual recognition of their conformity.

Other Approvals

UL1950

EN60950
