APPENDIX C • DATABASE TABLE CONFIGURATION
7 Beaver Brook Road, Littleton, MA 01460 • 978-486-0086 • www.burk.com
Name Type Size
LogMsg Text 32
AllowZeroLength: True
Attributes: Variable Length
Collating Order: General
ColumnHidden: False
ColumnOrder: Default
ColumnWidth: Default
DisplayControl: Text Box
Ordinal Position: 3
Required: True
Source Field: LogMsg
Source Table: UnitLogs_T
LogsNotes Text 50
AllowZeroLength: True
Attributes: Variable Length
Collating Order: General
ColumnHidden: False
ColumnOrder: Default
ColumnWidth: Default
Description: Notes according FCC rules Ea
DisplayControl: Text Box
Ordinal Position: 4
Required: False
Source Field: LogsNotes
Source Table: UnitLogs_T
Tab
le Indexes
Name Number of Fields
ID 1
Clustered: False
Distinct Count: 0
Foreign: False
Ignore Nulls: False
Name: ID
Primary: False
Required: False
Unique: False
Fields: ID, Ascending
LogTimeStamp 1
Clustered: False
Distinct Count: 0
Foreign: False
Ignore Nulls: False
Name: LogTimeStamp
Primary: False
Required: False
Unique: False
Fields: LogTimeStamp, Ascending
