Chapter 9 – SocketModem CDMA (MTSMC-C)

Multi-Tech Systems, Inc. Universal Socket Hardware Guide for Developers (S000342C) 122

Chapter 9 – SocketModem CDMA

(MTSMC-C)

The Multi-Tech SocketModem CDMA is a complete, ready-to-integrate, embedded wireless modem. Designed for

global use, it offers standards-based multi-band CDMA200 1x performance. The SocketModem CDMA is based on

industry-standard open interfaces and utilizes Multi-Tech’s universal socket design.

Notes about Activation:

• These units are shipped without network activation.

• To connect to the wireless network, you will have to establish a wireless account. Call Multi-Tech Systems,

Inc. to set up your account:

888-288-5470.

• See the Wireless Activation procedures in a separate document available on the Developer Kit CD.

Product Ordering Information

Product Description Region

Order this

Product

MTSMC-C-N1 800/1900 CDMA 1xRTT Generic SocketModem – 5 V Global

MTSMC-C-N2 800/1900 CDMA 1xRTT Sprint SocketModem – 5 V Global

MTSMC-C-N3 800/1900 CDMA 1xRTT Verizon SocketModem – 5 V Global

Antennas and Cables

45009650 Dual-band antenna for CDMA and F2 type modems

(Green Dot)

Global

45009630 SMA to MMCX COAX RF cable (6 inches) Global

45009670 Dual-band antenna for the F2-type and CDMA modems

½ Wave, Right Angle

Global

Developer Kit

MTSMC-DK SocketModem Wireless Developer Kit Global

Developer Kit

The SocketModem CDMA Developer Kit allows you to plug in the SocketModem and use it for testing,

programming, and evaluation. The kit includes:

• one developer board with RS-232 DB-25 connector

• universal power supply

• antenna

• RS-232 cable

• Developer Kit CD
